Accurate Laser welding head is designed by the body engineering design method, fully considering the comfort of the customer for
long-term use, and has the protective measures of the butt welding material to emit light, with multiple safety alarms, after
removing, the workpiece lock light automatic, high security. Accurate laser welding head can be equipped with nozzles of different
angles to meet the requirement of customers welding different products.
AC-Laser 1000W hand held fiber laser welding machine for stainless steel
Product Description
Product Description
PROJECT | PARAMETER | PROJECT | PARAMETER |
Device name | Handheld fiber Laser Welding Machine | Laser power | 500w, 800w, 1000w, 1500w, 2000w |
Laser system | Fiber optic laser | Laser wavelength | 1070nm |
Operation mode | Continous | Fiber length | Standard 10M (15M the longest support) |
Welding gun load | ≤2000w | Way of working | Continuous/modulation |
Power | 500w-2000w | Welder speed range | 0~120mm/s |
Core | 25um-100um | Cooling water machine | Industraial themostatic water tank |
Welding penetration | 0.39mm-4.57mm | Working environment temperature range | 15~35℃ |
Welding speed | ≤20m/min | Working environment humidity range | ＜70% No condensation |
Targeting | Built-in red light | Welding thickness recomendation | 0.5-3mm |
Welding material | Carbon steel, stainless steel, galvanized sheet, Aluminum, copper, etc | Welding gap requirements | ≤0.5mm |
Cooling method | Water cooling | Equipment size | 965mmL*565mmW*930mmH |
Introduction
Samples
Significant advantages
Different welding of non-standard metal parts, manual welding is more flexible. Perfect welding quality, small deformation, high penetration depth, no weld penetration. A variety of welding processes, spot welding, seam welding, welding, etc. High welding efficiency, replacing traditional TIG welding equipment. The largest welding benefit cost, no consumables, energy saving and environmental protection.
Company Profile
Exhibition & Visiting
Packing & Shiping
Our service
FAQ
